D-Link DAP-3220 Wireless 108G Exterior Access Point

wireless-108g-exterior-access-point-d-link-dap-3220

The DAP-3220 Wireless 108G Exterior Access Point connects 802.11g wireless devices to your wired network so that adding PCs to the network is a cable and hassle free task. Designed for outdoor environments, this access point creates an exterior “wireless” bubble to let outdoor users connect to the network and the Internet access.

Powerful & Durable Outdoor Solution

The DAP-3220 is designed to handle a wide variety of outdoor environments. It has a die-cast watertight housing, a built-in heater and a temperature sensor. Supporting 802.3af Power over Ethernet (PoE), it can
be placed at outdoor locations where power outlets are not easily accessible. Besides functioning as an AP, this device can be can be configured to operate as a Wireless Distribution System (WDS) to act as a bridge for linking together networks in different buildings.

// more

Posted 30 Apr 2009 by narmadi
Tags: , , , in Certification of D-Link Products // No Comments

Type Approval of Wireless N Router D-Link DIR-615

Type Approval about Wireless N Router D-Link DIR-615 [D-Link Product] is already Done, and here some information about the device

WIRELESS N ROUTER D-Link DIR-615

This Wireless N Router uses draft 802.11n technology with multiple intelligent antennas to maximize the speed and range of your wireless signals to significantly outperform 802.11g MIMO devices1. The antennas on the Wireless N Router make use of your home’s environment by bouncing multiple wireless signals off walls and ceilings to work around obstructions and help eliminate deadspots.

+ Secure wireless network using advanced WEP,
WPA, or WPA2 encryption

+ Easy to get started with D-Link Quick Router
Setup Utility

+ Backward compatible with 802.11g and 802.11b
devices including game consoles and digital
media player

Feature

Faster Wireless Networking – The DIR-615 provides up to 300Mbps* wireless connection with other 802.11n wireless clients. This capability allows users to participate in real-time activities online, such as video streaming, online gaming, and real-time audio. The performance of this 802.11n wireless router gives you the freedom of wireless networking at speeds 650% faster than 802.11g.

  • Compatible with 802.11b and 802.11g Devices – The DIR-615 is still fully compatible with the IEEE 802.11b standard, so it can connect with existing 802.11b PCI, USB and Cardbus adapters.
  • Advanced Firewall Features – The Web-based user interface displays a number of advanced network managementfeatures including: 1. Content Filtering – Easily applied content filtering based on MAC Address, URL, and/or Domain Name. 2.Filter Scheduling – These filters can be scheduled to be active on certain days or for a duration of hours or minutes.
  • Secure Multiple/Concurrent Sessions – The DIR-615 can pass through VPN sessions. It supports multiple and concurrent IPSec and PPTP sessions, so users behind the DIR-615 can securely access corporate networks.
  • User-friendly Setup Wizard – Through its easy-to-use Web-based user interface, the DIR-615 lets you control what information is accessible to those on the wireless network, whether from the Internet or from your company’s server. Configure your router to your specific settings within minutes.

* Maximum wireless signal rate derived from IEEE Standard 802.11g and Draft 802.11n specifications.

Technical Specification

Standards
+ IEEE 802.11n (draft)
+ IEEE 802.11g
+ IEEE 802.11b
+ IEEE 802.3
+ IEEE 802.3u

DEVICE INTERFACES
+ 4 10/100 LAN Ports
+ 1 10/100 WAN Port

ANTENNAS
Dual external 2dBi Gain reverse SMA antennas

SECURITY
+ 64/128-bit Wired Equivalent Privacy (WEP)
data encryption
+ Wi-Fi Protected Access (WPA, WPA2)

ADVANCED FIREWALL FEATURES
+ Network Address Translation (NAT)
+ Stateful Packet Inspection (SPI)
+ VPN Pass-through / Multi-sessions PPTP /
L2TP / IPSec

DEVICE MANAGEMENT
Internet Explorer v6 or later; Mozilla Firefox v1.5
or later; orother Java-enabled browsers

LEDs
+ Power
+ Status
+ WAN
+ WLAN (Wireless Connection)
+ LAN (10/100)
+ Internet Status

POWER INPUT
DC 5V 2.5A, through external power adapter

DIMENSIONS
193 x 116.8 x 30.5 mm (7.6 x 4.6 x 1.2 inches)

WEIGHT
940 grams (0.7 lb)

OPERATING TEMPERATURE
0º to 40º C

STORAGE TEMPERATURE
-20º to 65º C

OPERATING HUMIDITY
10% to 90%

STORAGE HUMIDITY
5% to 95%

CERTIFICATIONS
+ FCC Class B
+ IC
+ CE


Posted 01 Sep 2008 by narmadi
Tags: , , in Certification of D-Link Products // 1 Comment

Type Approval of Draft IEEE 802.11n Wireless Access Point "D-Link DAP-1353"

We have finishing Type Approval project of Draft IEEE 802.11n Wireless Access Point [D-Link DAP-1353]and the certificate already issued. Here some introduction about the device.

ULTIMATE PERFORMANCE
The D-Link RangeBooster N 650 Access Point DAP-1353 is a draft 802.11n compliant device that delivers real world performance of up to 650% faster than 802.11g wireless connection and transmission rates faster than 100Mbps wired Ethernet. 1 Providing connectivity for wireless computer users and wireless LAN nodes such as print servers on the 2.4GHz frequency band, this Access Point provides a fast wireless performance while remaining fully compatible with
802.11g and 802.11b devices.

Connect this RangeBooster N 650 Access Point to an Internet-enabled wired network and wirelessly share high-speed Internet. For superior performance, add other RangeBooster N 650 devices such as the RangeBooster N 650 notebook and desktop adapters, and enable a wireless coverage that extends to virtually every corner of your home or office.

EXTENDED HOME NETWORK COVERAGE
Powered by RangeBooster N 650 Technology, this high-performance Access Point provides superior network coverage while minimizing dead spots. Utilize the three adjustable antennas to configure optimal settings specific to your environment. The RangeBooster N 650 Access Point is designed for use in bigger homes/offices and for users that demand higher networking performance.

EASY TO SETUP, EASY TO USE
D-Link’s Wireless Network Wizard guides you step-by-step through the installation process. Configure this Access Point without having to call a networking expert to help you. Create a draft 802.11n wireless network with a data throughput capable of intense gaming, audio/video streaming, and large file transfers. Delivering best-in-class wireless performance, superior network security, and enhanced network coverage, the RangeBooster N 650 Access Point is an
integral piece for your next generation wireless network.

TECHNICAL SPECIFICATIONS

STANDARDS
+ IEEE 802.11n (draft)
+ IEEE 802.11g
+ IEEE 802.11b
+ IEEE 802.3
+ IEEE 802.3u

FREQUENCY RANGE
+ 2412 to 2462MHz (North America)
+ 2412 to 2472MHz (General Europe)

EMISSION SCHEMES
DSSS, OFDM

DATA MODULATION SCHEMES
DBPSK, DQPSK, CCK and OFDM
(BPSK/QPSK/16-QAM/64-QAM)

DATA RATES 1
+ 802.11g: 6/9/12/18/24/36/48/54Mbps
+ 802.11b: 1/2/5.5/11Mbps
+ 802.11n: 30/60/90/120/180/240/270/300
Mbps

TRANSMIT OUTPUT POWER 2
15dBm (typical)

EIRP
18dbm (typical)

ANTENNAS
3 detachable 3dBi Gain dipole antennas
(RP-SMA connectors)

ETHERNET INTERFACE
10/100BASE-TX port

SECURITY
+ 64/128-bit WEP data encryption
+ Wi-Fi Protected Access (WPA, WPA2)
+ Mac Address Filtering
+ 8 SSID for Network Segmentation
+ SSID broadcast disable Function
+ 802.1Q VLAN Tagging

OPeration Modes
+ Access Point
+ WDS with AP
+ WDS
+ AP Repeater
+ AP Client

Qos & Performance Enhancement
+ WMM (Wi-Fi Multimedia)
+ User Limit

DEVICE MANAGEMENT
+ Internet Explorer v6 or later; Mozilla
Firefox v1.5 or later; or other Javaenabled
browsers
+ Reset button
+ SNMP
+ Telnet
+ SSL/SSH protocol support

LED
+ Power
+ Status
+ WLAN
+ LAN (10/100)

POWER CONSUMPTION
9 Watts

POWER INPUT
5VDC 3A
Through external power adapter

DIMENSIONS
198 (L) x 120 (W) x 32 mm (H)
(7.8 x 4.72 x 1.26 inches)

Weight
325 grams (0.717 lb)
Operating Temperature
0°C to 40°C (32ºF to 104ºF)

Storage Temperature
-20°C to 65°C (-4ºF to 149ºF)

Operating Humidity
10% to 90% (non-condensing)

Storage Humidity
5% to 95% (non-condensing)

EMI CERTIFICATIONS
FCC Class B, CE, IC, C-Tick

SAFETY CERTIFICATION
CSA
